LSB200 Series

Miniature S-beam Load Cell

LSB200 Load Cell

Download the LSB200 Load Cell DatasheetDownload the datasheet

  • Compact sized S-beam (0.75 inches tall)
  • 0.7 ounces to 100 lbf capacity (20 grams to 445 Newtons)
  • Available in both aluminum (lower capacities) and stainless steel construction
  • Nonlinearity: ±0.05%
  • Deflection: 0.005" nominal
  • External matched output option available
  • Built-in overload protection
  • Female threads in US or metric
  • Connection options include a five-foot or a ten-foot 28 AWG 6 conductor shielded polyurethane cable
  • Weight: 0.3 oz (aluminum) or 0.9 oz (steel)
  • View Accessories
  • For use with the DI-5B38-05 or the DI-8B38-05. Use the DI-5B38-02 or the DI-8B38-02 for limited dynamic range applications.

The LSB200 series is widely used in medical bag weighing applications as well as automated feed back control and inline processing applications. The LSB200 series can be modified or customized to meet your requirements (contact DATAQ Customer Support for more information). This product is manufactured in the US and uses metal foil strain gauge technology.

      Material
    Capacity Aluminum Stainless Thread Cable Length (ft)
Buy Part Number Lbf Newtons Ounces Grams 2024-T4 17-4PH 4-40 M3x0.5 5 10
Contact Us FSH02319      0.35  10 checkmark     checkmark checkmark
FSH02666     0.7 20   checkmark
FSH02667         checkmark
FSH02535     1.8 50   checkmark
FSH02663         checkmark
FSH02536     3.5 100   checkmark
FSH02664         checkmark
FSH02602     8.8 250   checkmark
FSH02665         checkmark
FSH00091 1 4.5       checkmark
FSH00101         checkmark
FSH01559       checkmark     checkmark
FSH00092 2 8.9         checkmark
FSH00102         checkmark
FSH01748       checkmark     checkmark
FSH00093 5 22.3         checkmark
FSH00103         checkmark
FSH01887       checkmark     checkmark
FSH02235         checkmark
FSH00095 10 44.5       checkmark   checkmark
FSH00104         checkmark
FSH01888       checkmark     checkmark
FSH00096 25 111.3       checkmark   checkmark
FSH00105         checkmark
FSH02224           checkmark
FSH00097 50 222.5       checkmark   checkmark
FSH00106         checkmark
FSH02494       checkmark     checkmark
FSH00098 100 445.0         checkmark
FSH00107         checkmark
