LSB302 Series
Higher capacity S-beam Load Cell
- Anodized aluminum construction
- Built-in overload protection in both directions
- 25 to 300 lbf capacity (111.3 to 1335 Newtons)
- Nonlinearity: ±0.05%
- Deflection: 0.01" nominal
- Connection options include 4-pin LEMO receptacle or 28 AWG 6 conductor shielded polyurethane cable
- Male threads in US or metric
- Weight: 5 oz
- View Accessories
- For use with the DI-5B38-05 or the DI-8B38-05. Use the DI-5B38-02 or the DI-8B38-02 for limited dynamic range applications.
The S Beam Load Cell offers a compact design for platforms, silos, or scales. The LSB302 series can be modified or customized to meet your requirements (contact DATAQ Customer Support for more information). This product is manufactured in the US and uses metal foil strain gauge technology.
Material | ||||||||||||
Capacity | Thread | Cable Length (ft) | Aluminum 2024-T4 |
|||||||||
Buy | Part Number | Lbf | Newtons | 1/4-28 | 3/8-24 | M6X1 | M10X1.5 | 2 | 5 | 10 | LEMO | |
Contact Us | FSH00993 | 25 | 111.3 | |||||||||
FSH00998 | ||||||||||||
FSH01019 | ||||||||||||
FSH01020 | ||||||||||||
FSH01797 | ||||||||||||
FSH02080 | ||||||||||||
FSH02085 | ||||||||||||
FSH01012 | 50 | 222.5 | ||||||||||
FSH01022 | ||||||||||||
FSH01476 | ||||||||||||
FSH01798 | ||||||||||||
FSH02081 | ||||||||||||
FSH02086 | ||||||||||||
FSH00995 | 100 | 445.0 | ||||||||||
FSH00999 | ||||||||||||
FSH01013 | ||||||||||||
FSH01023 | ||||||||||||
FSH01024 | ||||||||||||
FSH01607 | ||||||||||||
FSH02082 | ||||||||||||
FSH02087 | ||||||||||||
FSH00996 | 200 | 890.0 | ||||||||||
FSH01000 | ||||||||||||
FSH01014 | ||||||||||||
FSH01025 | ||||||||||||
FSH01026 | ||||||||||||
FSH01035 | ||||||||||||
FSH02083 | ||||||||||||
FSH02088 | ||||||||||||
FSH00997 | 300 | 1335.0 | ||||||||||
FSH01001 | ||||||||||||
FSH01002 | ||||||||||||
FSH01010 | ||||||||||||
FSH01027 | ||||||||||||
FSH01028 | ||||||||||||
FSH02084 | ||||||||||||
FSH02089 |
