OXYGEN Data Acquisition Software

Version 3.7

$3,890.00
In
Stock

US orders ONLY.

  • Compatible with most Dewetron Hardware
  • All-in-one software for measurement, visualization, and analysis for many applications like Power Analysis, FFT, Order Analysis, and more
  • OXYGEN-SDK plugin interface for customization
  • Wide range of interfaces for testbed integration – including remote control capability via TCP/IP
  • Unlimited installations for data view and analysis (license-free)
  • Multiple precision measurement instruments and analysis functions increase the value of your measurements:
    • Scope
    • FFT
    • E-Power calculation (efficiency measurement)
    • XY chart
    • DMS-rosette strain gauge measurement
    • And many more
  • DejaView allows you to view and analyze all data from the start of the test, while data is still being recorded – an especially useful feature for long term testing. Live View: Live data is still visible at the same time on a different recorder, on the same or on a different screen.
  • Freely define your measurement screen(s), up to hundreds of channels. Keep track of all your data by using multiple measuring screens.
  • Use trigger functions to immediately capture any anomaly in the data. Split data from one recording to seperate data files.
  • Record any input over a long period of time:
    • Voltage
    • Current
    • Power
    • Temperature
    • Pressure
    • Acceleration
    • Strain gauge
    • And many more
Tweet this page Like this product on Facebook Share this page on LinkedIn Email this page
OXYGEN Data Acquisition Software
OXYGEN Data Acquisition Software
OXYGEN Data Acquisition Software

Watch Dewetron's YouTube Tutorials to familiarize yourself with OXYGEN software.

Description

OXYGEN Data Acquistion and Playback Software supports most Dewetron products. It is designed to be operated via touchscreen or classic mouse and keyboard and is pre-installed on the PU[REC] DAQ system. This all-in-one software for measurement, visualization, and analysis is suitable for many applications like Power Analysis, FFT, Order Analysis, and more.

OXYGEN is capable of continuous and synchronous acquisition of data from several sources: analog, digital, encoder, CAN, Ethernet, video, GPS and much more. Analog data is recorded at 50,000 to 200,000 samples per second per channel using the PUREC system.

Software Options

OXY-OPT-NET

Distributed Data Acquisition Software

$2500.00
Synchronized Ethernet Data Acquisition Option for PUREC Systems

Description

OXYGEN software option for distributed data acquisition via ethernet cable. Enables multiple PUREC data acquisition systems to be used like a single unit including synchronized data acquisition, data transfer, and remote channel configuration.

PUREC-OPT-CAN

CAN Bus Option

$1500.00
CAN Bus Option for PUREC Data Acquisition Systems

Description

PUREC option for 1x highspeed CAN Interface with up to 1 MBaud

OXY-OPT-CAN-OUT

CAN Bus OUT Option

$2200.00
Ethernet Receiver Option for PUREC Data Acquisition Systems

Description

OXYGEN option for transmitting measurement data via CAN Bus. Configured with a .dbc File. Requires PUREC-OPT-CAN Option.

Ethernet Receiver

OXYGEN Ethernet Option

$2500.00
Ethernet Receiver Option for PUREC Data Acquisition Systems

Description

OXYGEN option for receiving data via ethernet, powerful decoder configured with XML-description, synchronisation via input timestamp or included timestamp (milliseconds since midnight). Only UDP packets are supported

OXYGEN-UP-3-5

OXYGEN Software Upgrade

$1,945.00
OXYGEN Data Acquisition Software

Description

Update from existing OXYGEN-3.7 installations to OXYGEN-5.

Specifications

Minimum Requirements: Windows 64 bit operating system, 4GB RAM.
Compatible Hardware: PU[REC] Data Acquisition System, other Dewetron Systems

Videos

See the PUREC in action
PU[REC]

Get your fist look into the PU[REC] Data Acquisition System.
OXYGEN Playlist
OXYGEN

Watch Dewetron's list of tutorials on YouTube.
