Mixed Measurement Data Logger

Mixed measurement data loggers arte by definition multichannel devices that can make a variety of different measurements on a channel-by-channel basis. For example, simultaneous voltage, current, and temperature. Products with mixed measurement capability general exhibit more flexibility in the form of variable gains and wider sampling rates. Some products even feature built-in CJC sensors to support direct-connected thermocouples.

chckbox

Check the features you need

Measurement Type
Voltage ≤10V
Voltage ≤50V
Voltage >50V
Thermocouple
4-20mA process current
RTD
Strain-based sensor
Frequency/Rate/Count
Event, state, count
Environmental Temperature/RH
Interface
USB
Ethernet
WiFi
Deployment
Stand-alone
PC-connected
Price
<$250
<$500
<$1000
>$1000



DI-145 Data Acquisition Starter Kit
  • 4 analog channels
  • 240 Hz max sample rate
  • ±10 V fixed measurement range
  • Includes WinDaq software
  • Includes .NET Class
  • Documented command protocol for operation from any OS and platform
$29.00
Qty:
DI-149 Data Acquisition Starter Kit
  • 8 analog channels
  • Frequency and counter inputs
  • 10 kHz max sample rate
  • ±10 V fixed measurement range
  • Includes WinDaq software, Visual Studio .NET Class
  • Fully documented command protocol
$59.00
Qty:
DI-155 Data Acquisition Starter Kit
  • 4 analog channels
  • Frequency and counter inputs
  • 10 kHz max sample rate
  • ±2.5 to ±50 V full scale range
  • Includes WinDaq software, Visual Studio .NET Class
  • Fully documented command protocol
$149.00
Qty:
DI-245 Voltage and Thermocouple Data Acquisition System
  • 4 differential and isolated channels
  • Programmable Voltage or TC type (per channel)
  • ±10mV to ±50V measurement range
  • Supports J, K, T, B, R, S, E, and N Thermocouple types
  • Fully documented command protocol
$299.00
Qty:
DI-2108 High Speed Data Acquisition System
  • 8 differential analog inputs
  • Anti-alias filter per channel
  • ±10V measurement range
  • Up to 220 kHz throughput
  • 16-bit resolution
  • 7 Digital Ports with rate and count
  • Includes WinDaq/Lite software
$259
Qty:
DI-160 Event, State, Count Data Logger
  • Measures when, how long, and how many events occur
  • Eight input channels
  • Isolated high voltage inputs connect to 230 VAC rms source
  • 21 sample intervals (1 sec to 24 hrs)
  • Record forever to a 2 GB SD card
$299.00
Qty:
DI-1000 Thermocouple Data Acquisition
  • 4 thermocouple channels
  • 1000-V input-to-output and channel-to-channel isolation
  • Supports most TC types
  • Daisy-chain DI-1000TC units for higher channel count
$495.00
Qty:
DI-710 Data Acquisition and Data Logger Systems
  • 16 analog inputs
  • 4800 Hz max sample rate
  • ±1.25 V to ±10 V programmable ranges
  • Measure environmental temperature
    & humidity with HMP60 probe
  • Includes WinDaq software
$499.00
Qty:
DI-710 Data Acquisition and Data Logger Systems
  • 16 analog inputs
  • 4800 Hz max sample rate
  • ±10 mV to ±10 V programmable ranges
  • Better than 2 μV resolution on the 10 mV range
  • Includes WinDaq software
$499.00
Qty:
DI-710 Data Acquisition and Data Logger Systems
  • 16 analog inputs
  • 4800 Hz max sample rate
  • ±1.25 to ±10 V programmable ranges
  • Measure environmental temperature
    & humidity with HMP60 probe
  • LAN-compatible Ethernet interface
  • Includes WinDaq software
$599.00
Qty:
DI-710 Data Acquisition and Data Logger Systems
  • 16 analog inputs
  • 4800 Hz max sample rate
  • ±10mV to ±10V programmable ranges
  • Better than 2 μV resolution on the 10 mV range
  • LAN-compatible Ethernet interface
  • Includes WinDaq software
$599.00
Qty:
DI-710 Data Acquisition and Data Logger Systems
  • 16 analog inputs
  • 14.4 kHz max sample rate
  • ±1.25 V to ±10 V programmable ranges
  • Records to PC or SD memory
  • Measure environmental temperature
    & humidity with HMP60 probe
$599.00
Qty:
DI-710 Data Acquisition and Data Logger Systems
  • 16 analog inputs
  • 14.4 kHz max sample rate
  • ±10 mV to ±10 V programmable ranges
  • Records to PC or SD memory
  • Better than 2 μV resolution on the 10 mV range
$599.00
Qty:
DI-718B Data Acquisition and Data Logger Systems
  • 8 analog inputs
  • 4800 Hz max sample rate
  • Uses isolated 8B amplifier modules
  • Makes any industrial measurement
  • Small form factor fits into tight spaces
  • Wide power supply range (9-36 Vdc)
  • Includes WinDaq software
$595.00
Qty:
DI-161 Event, State, Count Data Logger
  • Measures when, how long, and how many events occur
  • Ethernet-based
  • 8 discrete and isolated input channels
  • 240 V rms c signal range
  • Stores text or database files directly to a Windows server
$629.00
Qty:
DI-718B Data Acquisition and Data Logger Systems
  • 8 analog inputs
  • Up to 14.4 kHz max sample rate
  • Any industrial measurement
  • Uses isolated 8B amplifier modules
  • Records to PC or SD memory
  • Small form factor fits into tight spaces
  • Includes WinDaq software
$695.00
Qty:
DI-710 Data Acquisition and Data Logger Systems
  • 16 analog inputs
  • 14.4 kHz max sample rate
  • ±1.25 to ±10 V programmable ranges
  • Records to PC or SD memory
  • Measure environmental temperature
    & humidity with HMP60 probe
  • Includes WinDaq software
$799.00
Qty:
DI-710 Data Acquisition and Data Logger Systems
  • 16 analog inputs
  • 14.4 kHz max sample rate
  • ±10mV to ±10V programmable ranges
  • Records to PC or SD memory
  • Better than 2 μV resolution on the 10 mV range
  • Includes WinDaq software
$799.00
Qty:
DI-718B Data Acquisition and Data Logger Systems
  • 8 analog inputs
  • 4800 Hz max sample rate
  • Any industrial measurement
  • Uses isolated 8B amplifier modules
  • Small form factor fits into tight spaces
  • Wide power supply range (9-36 Vdc)
  • Includes WinDaq software
$795.00
Qty:
DI-1000 Thermocouple Data Acquisition
  • 8 thermocouple channels
  • 1000-V isolation between channels
  • Supports J, K, T, E, S, B, and R Thermocouple types
  • Daisy-chain DI-1000TC units for higher channel count
$895.00
Qty:
DI-718B Data Acquisition and Data Logger Systems
  • 8 analog inputs
  • 14.4 kHz max sample rate
  • Any industrial measurement
  • Uses isolated 8B amplifier modules
  • Records to PC or SD memory
  • Small form factor fits into tight spaces
  • Includes WinDaq software
$895.00
Qty:
DI-808 Voltage and Thermocouple Data Logger
  • Works with any smart device
  • TC, mV, V, pulse inputs
  • Advanced triggering functions
  • Alarm outputs with email/text alerts
  • Manage, receive and retrieve data from across the room, or the other side of the planet
$995.00
Qty:
DI-5001 Data Acquisition Board
  • 32 analog inputs
  • 8 each discrete inputs and outputs
  • 200 kHz sample rate
  • ±1.25 to ±10 V programmable ranges per channel
  • Includes WinDaq software
  • Provided with ActiveX Control set
$1195.00
Qty:
DI-5001 Data Acquisition Board
  • 32 analog inputs
  • 8 each discrete inputs and outputs
  • 200 kHz sample rate
  • ±0.625 to ±5 V programmable ranges per channel
  • Includes WinDaq software
  • Provided with ActiveX Control set
$1195.00
Qty:
DI-5001 Data Acquisition Board
$1390.00
Qty:
DI-5001 Data Acquisition Board
$1390.00
Qty:
DI-718Bx Data Acquisition and Data Logger Systems
  • 16 analog inputs
  • 4800 Hz max sample rate
  • Any industrial measurement
  • Uses isolated 8B amplifier modules
  • Includes WinDaq software
  • Wide power supply range (9-36 Vdc)
  • Provided with ActiveX Control set
$1395.00
Qty:
DI-720 Data Acquisition Systems
$1395.00
Qty:
DI-718Bx Data Acquisition and Data Logger Systems
  • 16 analog inputs
  • 14.4 kHz max sample rate
  • Any industrial measurement
  • Uses isolated 8B amplifier modules
  • Records to PC or SD memory
  • Includes WinDaq software
  • Wide power supply range (9-36 Vdc)
$1495.00
Qty:
DI-720 Data Acquisition Systems
$1590.00
Qty:
DI-722 Data Acquisition Systems
  • 32 ruggedized, differential analog inputs
  • Protected to 120 Vrms
  • 50 kHz max sample rate
  • ±2.5 to ±20 V programmable ranges
  • Includes WinDaq software
  • Wide power supply range (9-36 V dc)
$1995.00
Qty:
DI-722 Data Acquisition Systems
$2185.00
Qty:
DI-730 Industrial Data Acquisition Systems
$3195.00
Qty:
DI-730 Industrial Data Acquisition Systems
$3390.00
Qty:
DI-785 Industrial Data Acquisition System
$3995.00
Qty:
DI-788 Industrial Data Acquisition System
$3995.00
Qty:
GL240 Stand-alone USB data logger
  • 10 isolated analog/4 counter channels
  • Sample intervals from 10ms to 1 hour
  • ±20mV to ±100V programmable ranges
  • Supports TC measurements
  • Record to PC, USB drive, flash
  • Measure RH model B-530
$1095.00
Qty:
GL840 Stand-alone USB data logger
  • 20 isolated analog/4 counter channels
  • 60V common mode voltage
  • ±20mV to ±100V programmable ranges
  • Supports TC measurements
  • Record to PC, USB drive, flash
  • Measure RH with model B-530
$2495.00
Qty:
GL840 Stand-alone USB data logger
  • 20 isolated analog/4 counter channels
  • 300V common mode voltage
  • ±20mV to ±100V programmable ranges
  • Supports TC measurements
  • Record to PC, USB drive, flash
  • Measure RH with model B-530
$2945.00
Qty:
GL900 Industrial Stand-alone USB data logger
  • 8 isolated analog channels
  • 10µs to 1 minute sample intervals
  • ±20mV to ±500V programmable ranges
  • Supports most TC types
  • Record to PC, USB drive, flash
  • Measure RH with the B-530 sensor
$4295.00
Qty:
MT100 Multifunction Stand-alone USB data logger
$3295.00
Qty:
GL7000 Modular Stand-alone Data Logger
$2400.00
Qty:
