UTRID-16

Multi-Use PDF Temperature Logger -30°C to +60°C (-22°F to +140°F)

$72
In
Stock
  • -30°C to +60°C (-22°F to +140°F) measurement range
  • 8000 sets of humidity and temperature readings
  • Ideal for transportation applications
  • Display shows temperature and alarm status of up to six alarms
  • Don't need USB Craddle to download and setup
Tweet this page Like this product on Facebook Share this page on LinkedIn Email this page
EL-USB-1 Data Logger

Description

UTRID-16 provides a display to allow immediate viewing of current and past temperature and alarm statistics.

The display shows recording status, current temperature, alarm status of up to six user-configurable alarms and duration of any temperature excursions.

When the UTRID-16 is connected to a computer using the integrated USB plug, a detailed PDF report of the recorded temperature data and alarms can be automatically generated without the need for extra accessories and proprietary software.

For more detailed data analysis, the UTRID-16 also creates an encrypted data file compatible with LogTag Analyzer® operating software and data management options.



Accessories

LT-CERT-2

Calibration Certificate

$54.00
NIST Calibration Certificate

Description

Two point (-20C and +40C) calibration for LogTag loggers. Please Note: Calibration certificates cannot be returned for a refund. These calibration certificates have a typical lead time of 1-2 weeks.

Software

LogTag Analyzer

Configuration Software

LogTag® Analyzer 3 features configuration profiles, import/export of option settings, configuration and download logging and also allows configuration and download of USB loggers

Lascar EL-BT EasyLog Software

LogTag Xpress

Configuration Software

LogTag® Xpress is a sophisticated alternative to the powerful LogTag® Analyzer software. With a stripped-down feature set, LogTag® Xpress focuses on efficiently configuring and downloading the complete range of LogTag® data logging products, with as little user interaction as possible.

Lascar EL-BT EasyLog Software

LogTag Online

Management Software

LogTag Online is a Cloud-based online environmental management system providing alarm notifications, compliance, record storage and reporting functions.

Lascar EL-BT EasyLog Software

Specifications

Measurement Range: -30°C to +60°C (-22°F to +140°F)
Accuracy (overall error):
Better than ±0.5°C (±0.9°F) for -20°C to +40°C (-4°F to +104°F).
Better than ±0.7°C (±1.3°F) for -25°C to -20°C (-13°F to -4°F) & +40°C to +60°C (+104°F to +140°F).
Recording Capacity: 16,129 temperature readings. 56 days @ 5min logging, 168 days @ 15min logging.
Statistics memory (for display on LCD):Max/Min values and alarm duration values.
Sample interval
Configurable from 30 seconds to 18 hours..
Battery Life 2 years storage, followed by 6 months of operation life.
Real Time Clock Rated accuracy ±25ppm @ 25°C (equivalent to 2.5 seconds/day).
Rated temperature coefficient is -0.034 ±0.006ppm/°C (I.e typically +/- 0.00294 seconds/day/°C).
