HASO-8

Description

HASO-8 single-use Humidity and Temperature Logger measures and stores up to 8000 sets of high-resolution humidity and temperature readings over a measurement range of 0 to 100%RH and -40°C to +85°C (-40°F to +185°F).

Enclosed in a robust and durable polycarbonate case – the HASO-8 is equipped with a unique temperature sensor arrangement providing a fast reaction time to temperature change and a real-time clock that provides date/time stamps for each temperature reading.

Using the LogTag Interface and LogTag’s freely available companion software LogTag Analyzer, the LogTag is easily set up for recording conditions including delayed start, sampling interval, number of readings, a continuous or fixed number of readings, and configuration of conditions to activate the ALERT indicator.

Readings are downloaded using LogTag Analyzer which provides facilities for charting, zooming, and listing data statistics and allows exporting the data to other applications such as Excel.

HASO-8 complies with the relevant international standards for temperature monitoring devices:- FDA 21 CFR Part 11, EC Annex 11, IATA’s 2018 Dangerous Goods Regulations 59th Edition, FCC, CE, RCM, and RoHS. This demonstrates the quality and suitability of the LogTag® HASO-8 for temperature monitoring applications where accuracy and consistency are required.

Accessories

Software

Specifications

Measurement Range:	0 to 100%RH and -40 to 185°F (-40 to 85°C)
Accuracy (overall error):	Better than ±0.45°C (±0.8°F) for +0°C to +50°C (+32°F to +122°F), typically ±0.3°C (0.6°F). Better than ±0.8°C (±1.4°F) for +50°C to +80°C (+122°F to +176°F), typically ±0.5°C (0.9°F). Better than ±0.95°C (±1.7°F) for -40°C to +0°C (-40°F to +32°F), typically ±0.6°C (1.1°F). Better than ±5%RH for 10%RH to 80%RH. Better than ±6%RH for 0%RH to 10%RH. Better than ±7%RH for 80%RH to 100%RH.
Recording Capacity:	8,003 pairs of humidity and temperature readings. 53 days @ 10min logging, 80 days @ 15min logging.
Sample interval	Configurable from 30 seconds to several hours. (Typically 5 minute logging).
Battery Life	2 years storage, followed by 6 months of operation life.
Real Time Clock	Rated accuracy ±25ppm @ 25°C (equivalent to 2.5 seconds/day). Rated temperature coefficient is -0.034 ±0.006ppm/°C (I.e typically +/- 0.00294 seconds/day/°C).
